View In:   ArcGIS Online Map Viewer

Name: All Roads

Display Field: RouteId

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The Caltrans All Roads Linear Referencing Services (LRS) dataset provides the base geometry for federally required Highway Performance Monitoring System (HPMS) business data, functionally classified roads for the California Roads System (CRS) (a requirement for federal funding of local agency projects), and the State Highway Network (SHN), which supports a wide range of internal Caltrans business needs. Description The Federal Highway Administration (FHWA) requires all state DOT's to develop and submit a Linear Referencing System (LRS) network for all public roads in their respective states known as the All Roads Network of Linear Referenced Data (ARNOLD). This ARNOLD requirement is an integral part of each state’s federally mandated Highway Performance Monitoring System (HPMS) annual submittal. To meet the ARNOLD requirement, the Division of Research, Innovation and System Information (DRISI) has developed a representation of all roads in California using a combination of the Census Bureau’s Topologically Integrated Geographic Encoding and Reference (TIGER) files and previously developed line work representing the State Highway System. This data is published publicly.

Service Item Id: 93d1cf08155c4999893318ea33025ec8

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: -414484.66810080584
YMin: -608546.6957065426
XMax: 551540.2208792731
YMax: 458457.952550645
Spatial Reference: 3310  (3310)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 92, 230, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• RouteId ( type: esriFieldTypeString, alias: RouteId, editable: true, nullable: true, length: 75, defaultValue: null, modelName: RouteId )
• LRSFromDate ( type: esriFieldTypeDate, alias: LRSFromDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LRSFromDate )
• LRSToDate ( type: esriFieldTypeDate, alias: LRSToDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LRSToDate )
• CreatedUser ( type: esriFieldTypeString, alias: CreatedUser, editable: true, nullable: true, length: 30, defaultValue: null, modelName: CreatedUser )
• CreatedDate ( type: esriFieldTypeDate, alias: CreatedDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: CreatedDate )
• LastEditedUser ( type: esriFieldTypeString, alias: LastEditedUser, editable: true, nullable: true, length: 30, defaultValue: null, modelName: LastEditedUser )
• LastEditedDate ( type: esriFieldTypeDate, alias: LastEditedDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LastEditedDate )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: true, defaultValue: null, modelName: Shape.STLength() )

Templates:

• Name: All Roads
  Description:
  Prototype:
  LastEditedUser: null
  LastEditedDate: null
  RouteId: null
  LRSFromDate: null
  LRSToDate: null
  CreatedUser: null
  CreatedDate: null

  Drawing Tool: esriFeatureEditToolLine

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
