Name: All Roads

Display Field: RouteId

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The Federal Highway Administration (FHWA) requires all state DOT's to develop and submit a Linear Referencing System (LRS) network for all public roads in their respective states known as the All Roads Network of Linear Referenced Data (ARNOLD). This ARNOLD requirement is an integral part of each state’s federally mandated Highway Performance Monitoring System (HPMS) annual submittal. To meet the ARNOLD requirement, the Division of Research, Innovation and System Information (DRISI) has developed a representation of all roads in California using a combination of the Census Bureau’s Topologically Integrated Geographic Encoding and Reference (TIGER) files and previously developed line work representing the State Highway System. This data is published publicly.</SPAN></P></DIV></DIV></DIV>

Service Item Id: 836c3a3e2e7f40b8b36b24addf01cf14

Copyright Text: Caltrans, Division of Research, Innovation and System Innovation, Office of Data Services and Technology, Linear Referencing Services (LRS) Branch

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.38488617581E7
YMin: 3833714.521399997
XMax: -1.2705439114E7
YMax: 5162299.121799998
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [115, 178, 255, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• RouteId ( type: esriFieldTypeString, alias: RouteId, length: 75 )
• LRSFromDate ( type: esriFieldTypeDate, alias: LRSFromDate, length: 8 )
• LRSToDate ( type: esriFieldTypeDate, alias: LRSToDate, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
