View In:   ArcGIS Online Map Viewer

Name: SHN Postmiles

Display Field: RouteId

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The LRSN_Postmile feature class is an Esri Roads and Highways Network (or more generically a Linear Referencing Method) that represents the California State Highway System (Interstates, US Highways and State Highways) using the Caltrans Postmile System.The Caltrans Postmile System is fairly complex, where postmiles reset to 0.0 at county boundaries, temporality is managed through Postmile Prefixes and "Independent Alignments" (where right and left sides diverge around various obstacles and are postmiled differently) are managed with Postmile Suffixes. To accommodate this system, entire "Signed Routes" (e.g. 800+ miles of Interstate 5) are divided into a number of "Postmile Routes", where the Postmile Prefix and Postmile Suffix are managed as part of the Route ID, leaving just the numeric portion of the Postmile as the Postmile Route Measure.Additionally, while the Caltrans Postmile System is considered a "Centerline" system (with the exception of the aforementioned independent alignments), the LRSN_Postmile Network stores complete right and left "Carriageways" (the R/L carriageway designation is also part of the Route ID). The reason for this is to best support independent alignments AND to meet Federal Highway Administration requirements for every state's Linear Referencing System.To accommodate division of entire signed routes into multiple Postmile Routes, LRSN_Postmile is configured as a Roads and Highways "Line Feature", where every individual Postmile Route that comprises a Signed Route is tagged with a "Line ID" common to the Signed Route. This supports the ability to perform Dynamic Segmentation of linear events that begin on one Postmile Route and end on another, and the ability to automatically derive the Odometer Network directly from the Postmile Network.The Postmile Network is one of three Roads and Highways Networks maintained in Roads and Highways by Caltrans. The other two are the Odometer Network (also State Highway System only, and derived from the Postmile Network) and the AllRoads Network, which represents all public roads in California (not just state highways).

Service Item Id: 157bc1893bce4699b72e786cb548e22d

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: -401129.8139690088
YMin: -607491.2750960104
XMax: 536129.2042001142
YMax: 457262.3636848405
Spatial Reference: 3310  (3310)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 92, 230, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• RouteId ( type: esriFieldTypeString, alias: RouteId, editable: true, nullable: true, length: 75, defaultValue: null, modelName: RouteId )
• County ( type: esriFieldTypeString, alias: County, editable: true, nullable: true, length: 3, defaultValue: null, modelName: County )
• RouteNum ( type: esriFieldTypeString, alias: RouteNum, editable: true, nullable: true, length: 3, defaultValue: null, modelName: RouteNum )
• RouteSuffix ( type: esriFieldTypeString, alias: RouteSuffix, editable: true, nullable: true, length: 1, defaultValue: null, modelName: RouteSuffix )
• PMPrefix ( type: esriFieldTypeString, alias: PMPrefix, editable: true, nullable: true, length: 1, defaultValue: null, modelName: PMPrefix )
• PMSuffix ( type: esriFieldTypeString, alias: PMSuffix, editable: true, nullable: true, length: 1, defaultValue: null, modelName: PMSuffix )
• Alignment ( type: esriFieldTypeString, alias: Alignment, editable: true, nullable: true, length: 1, defaultValue: null, modelName: Alignment )
• LineId ( type: esriFieldTypeString, alias: LineId, editable: true, nullable: true, length: 75, defaultValue: null, modelName: LineId )
• LineOrder ( type: esriFieldTypeInteger, alias: LineOrder, editable: true, nullable: true, defaultValue: null, modelName: LineOrder )
• LRSFromDate ( type: esriFieldTypeDate, alias: LRSFromDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LRSFromDate )
• LRSToDate ( type: esriFieldTypeDate, alias: LRSToDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LRSToDate )
• CreatedUser ( type: esriFieldTypeString, alias: CreatedUser, editable: true, nullable: true, length: 30, defaultValue: null, modelName: CreatedUser )
• CreatedDate ( type: esriFieldTypeDate, alias: CreatedDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: CreatedDate )
• LastEditedUser ( type: esriFieldTypeString, alias: LastEditedUser, editable: true, nullable: true, length: 30, defaultValue: null, modelName: LastEditedUser )
• LastEditedDate ( type: esriFieldTypeDate, alias: LastEditedDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LastEditedDate )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: true, defaultValue: null, modelName: Shape.STLength() )

Templates:

• Name: SHN Postmiles
  Description:
  Prototype:
  LastEditedUser: null
  LastEditedDate: null
  RouteId: null
  County: null
  RouteNum: null
  RouteSuffix: null
  PMPrefix: null
  PMSuffix: null
  Alignment: null
  LineId: null
  LineOrder: null
  LRSFromDate: null
  LRSToDate: null
  CreatedUser: null
  CreatedDate: null

  Drawing Tool: esriFeatureEditToolLine

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
